Ruptela Trace5
Ruptela Trace5 is a compact GNSS-based Automatic Vehicle Location (AVL) tracker with all essential vehicle tracking and fleet management features. The GPS tracker suits logistics, delivery, utility services, car rental and vehicle financing use cases. This GNSS tracker uses LTE Cat M1/NB2 (4G) connectivity, a 2G fallback network, and a premium GPS module from Ublox. IP67 version with rugged housing is also available, fully protecting the device from water, dirt and mechanical factors. Vehicle tracking GPS device can be installed outside the cabin (i.e. near the engine) and successfully operate.
Server Connection
- Indian Region 52.74.44.145
- Rest of the World 15.184.246.16
- Server Port 8624
Basic Information
- Purpose Vehicle
- Weight Rugged: 185 g (6.53 oz.), Regular: 70 g (2.47 oz.)
Connectivity Information
- Network Signal Level Yes
- Network Operator ID Yes
Locational Information
- GNSS Signal Level Yes
- LBS Yes
Features
- Odometer Yes
- Remote outputs control Yes
- Hardware key Yes
- Motion Sensor Yes
- 4G/LTE Yes
Interfaces
- Discrete Inputs 5
- Number of Outputs 2
- Analog sensor Yes
Highlights
- Geofencing
- Parking mode
- Ignition source
- ECO driving
Events Monitored
- Car crash
- Deviation from the route
- Distance between objects
- Driver change
- Engine excessive idling
- Entrance or exit from geofence
- Excessive driving
- Excessive parking
- External power cut
- Fuel level change
- GSM jamming
- Harsh driving
- Inputs triggering
- Low battery
- Outputs triggering
- Parameter in range
- Parking state detection
- Pressing SOS button
- Shake sensor
- Speeding (hardware related)
- Speeding (platform related)
- State field value
- Task status change
- Tracker switched OFF or lost connection
- Unauthorized movement
Check Out Other Devices By AVL Devices
-
Ruptela FM-Tco4
Ruptela FM-TCO4 is the fourth generation advanced, low power consumption but powerful tracking device. It acquires position by GPS/GLONASS signal and transfers data to the server via the GPRS cellular network. It even provides accelerometer data for ECO-Drive, Dual CAN support and standard OBD functionality.
-
Ruptela FM-Pro3
Ruptela FM-Pro3 is a terminal with GPS/GSM connectivity that can determine the object’s coordinates and transfer them via the GSM network. It also has two simplified RS232 ports to connect additional equipment, such as a Personal Navigation Device, a digital fuel level sensor.
-
ATrack AK11
